| Marine Cable Glands |
| |
|
|
|
| |
|
 Marine Cable Glands Details : |
| |
| Size |
10 mm to 90 mm |
| Application |
Outdoor or Indoor for use with all types of braided or unarmoured Marine electrical cable fittings |
| Ingress Protection |
IP54 IP66 |
| Optional Thread |
ISO Metric, NPT, NPS, BSP, BSPT, PG |
| Finish |
Chrome Finish, Brass Finish, Nickel Finish or as specified |
| Material |
Brass BS 2874 CZ121 Pb3 |
| Sizes |
Metric from 10 mm to 60 mm in JIS, PG 7 to PG 48 in DIN from M 16 to M 90 in BS |
|
| |
| Technical Data : |
| |
| Size |
A |
B |
C |
D |
E |
F |
G |
H |
I |
| 10 |
45.00 |
21.50 |
10.00 |
3/8" BSP |
11.00 |
5.00 |
28.00 |
22.00 |
4.00 |
| 15 |
50.00 |
27.50 |
15.00 |
1/2" BSP |
11.00 |
5.00 |
31.20 |
26.20 |
4.00 |
| 20 |
53.00 |
33.50 |
20.00 |
3/4" BSP |
10.00 |
5.00 |
37.00 |
32.00 |
6.00 |
| 25 |
60.00 |
41.50 |
25.00 |
1" BSP |
11.00 |
6.00 |
46.00 |
40.00 |
6.00 |
| 30 |
65.00 |
49.50 |
30.00 |
1.1/4" BSP |
12.00 |
6.00 |
56.00 |
48.00 |
8.00 |
| 35 |
70.00 |
55.50 |
40.00 |
1.1/2" BSP |
12.00 |
6.00 |
63.000 |
55.00 |
8.00 |
| 40 |
70.00 |
55.50 |
40.00 |
1.1/2" BSP |
12.00 |
6.00 |
63.00 |
55.00 |
8.00 |
| 45 |
85.00 |
69.50 |
50.00 |
2" BSP |
12.00 |
6.00 |
76.00 |
67.00 |
10.00 |
| 50 |
85.00 |
69.50 |
50.00 |
2" BSP |
12.00 |
6.00 |
76.00 |
67.00 |
10.00 |
| 55 |
87.00 |
85.50 |
60.00 |
2.1/2" BSP |
12.00 |
6.00 |
95.00 |
86.00 |
10.00 |
| 60 |
88.00 |
85.50 |
60.00 |
2.1/2" BSP |
12.00 |
6.00 |
95.00 |
86.00 |
10.00 |
| 65 |
100.00 |
99.50 |
70.00 |
3" BSP |
14.00 |
6.00 |
112.00 |
100.00 |
12.00 |
| 70 |
110.00 |
99.50 |
70.00 |
3" BSP |
14.00 |
6.00 |
112.00 |
100.00 |
12.00 |
|
| |
| Any kind of marine cable glands, brass cable glands can be developed and supplied exactly as per Customer Specifications & Requirement. |
| |
|
|
| |
|
|
|
|
|
|
|
